Eclipse Magnetics Guides Magnetic Material Decisions from Concept to Production

Our advisory workflow helps purchasing, design and quality teams move from a requested holding force to a manufacturable magnetic assembly. Engineers compare magnetic family, coating, magnetization orientation, operating temperature, safety margin and inspection evidence before the quote is finalized. The result is a recommendation that is practical for sourcing and defensible for technical review.

Start a Design Review
Magnetic engineering review desk

Guided Advisor

A clear service path for magnet grade, geometry and validation.

01

Application intake

We capture the target holding force, air gap, mating material, cleaning exposure, maximum temperature, duty cycle and regulatory documentation needs. That prevents a catalog part from being selected without the conditions that actually drive magnetic performance.

02

Material family shortlist

NdFeB, ferrite, SmCo and bonded magnetic materials are compared by energy product, reversible temperature coefficient, corrosion pathway, brittleness, cost stability and available geometries. Buyers receive a concise reason for each recommendation.

03

Assembly engineering

For housed magnets, separator bars and custom holders, our team reviews flux return paths, adhesive retention, pole layout and mechanical protection. Design notes call out the features that are essential for repeatable production.

04

Inspection handoff

Prototype data, magnetization settings, coating checks and lot traceability are summarized so quality teams can receive the same performance logic that guided the original specification.

Inline FAQ

Common questions before a magnetic material review starts.

The strongest starting point is a drawing or envelope, the working air gap, mating steel details, required holding force, operating temperature, coating exposure and annual volume. If those values are not final, Eclipse Magnetics can still provide a decision tree that shows which unknowns matter most.

Sometimes, but only when the available volume, pole face area and circuit design can compensate for lower energy density. Our engineers compare the geometry first, because material price alone rarely tells the full cost of the magnetic system.

Review it before tooling and mounting features are frozen. Magnetic assemblies depend on pole direction, keeper material, adhesive area, service temperature and access for inspection; late changes can force expensive redesigns.

Before and After

Replacing guesswork with controlled magnetic evidence.

Before review

A project team starts with a magnet size copied from a legacy build. The holding force is measured in an uncontrolled fixture, coating is chosen after purchasing asks for a lower price, and the supplier receives incomplete notes about heat and humidity.

  • Unclear safety margin
  • Coating mismatch risk
  • Weak lot documentation

After review

The magnet family, pole orientation, coating, inspection method and assembly constraints are written into the request. Samples are measured in a repeatable fixture and production lots can be compared against a known performance target.

  • Defined test condition
  • Material rationale recorded
  • Traceability ready for QA

Service CTA

Request a magnetic material audit from Eclipse Magnetics.

Send the design conditions, target force and preferred delivery window. We will respond with the practical next step for sample review or production quotation.
